Timing chain Issues

I was washing my grizzly today to find this bolt very loose with oil around it. At the time I wasn't quite sure what it was, after calling someone I found out it was the timing chain tensioner. In another thread I had commented about how my bike is continually getting harder and harder to start, and it also making a loud clacking noise. When I started it today it I held on the starter button for about 6 seconds(it just turning over)before it tried to fire-off..the entire time making this loud noise. As soon as it turned over it blew a strong puff of dust out of my intake(snorkles)..is that normal?

If this was loose I would assume the tensioner wasn't holding the chain tight enough, right?

I'm afraid that if the tension isn't right then the timing is off and the loud noise may be the piston hitting the valves. It is a very solid, and very loud metal to metal sound.

Is any of this accurate or could anyone please give me some advice on this? I'm kinda freaked out by all of this.



Reply With Quote
EzekielRoyale is offlineReport Post

Grizzrider08's Avatar

Join Date: Mar 2008
Age: 23
Posts: 2,271
Thanks: 119
Thanked 315 Times in 266 Posts
Rep Power: 84
Grizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond reputeGrizzrider08 has a reputation beyond repute
Location: Vernon, NJ

Quote
#2
06-12-2009, 08:48 PM
Well if the tensioner is tight and hasnt adjusted, the sound your hearing could be the timing chain slapping around. Is the bolt tight? I dont know what kind of timing chain adjuster the bike has, but i know on some bikes that arent auto tensioning you need to loosen the bolt, the tensioner tightens up, and tighten the bolt back up.
__________________
08' Grizzly 700 EPS: US Yamaha front brushguard, Full ricochet skids, 3.5" Rox risers, solex bars, odi grips, rox handguards, 27" Maxxis zillas, Tamarack Classic box, Viper 3k winch, 2r tip, 2r foot pegs and traction rails, 2r front receiver, uni filter, pod mod, hanger mod, greasless, Rigid D2s, Rigid 10" SR


2013 Can Am Renegade 1000 XXC

Lots o' mods
Reply With Quote
Grizzrider08 is online nowReport Post

Join Date: Nov 2008
Age: 27
Posts: 311
Thanks: 2
Thanked 16 Times in 16 Posts
Rep Power: 71
EzekielRoyale has a spectacular aura aboutEzekielRoyale has a spectacular aura about
Location: Pickering, Louisiana

Quote
#3
06-12-2009, 09:50 PM
I tightened the bolt now, but it still makes the same noise. I don't know whats going on inside there. I don't know as much about these motors as I should and thats becoming readily apparent. I looked on Yamaha on the exploded parts view. I don't think it was the chain itself slapping around because of the guides on either side of it. I could very well be wrong.

Last edited by EzekielRoyale; 06-12-2009 at 09:50 PM..
Reply With Quote
EzekielRoyale is offlineReport Post

Join Date: Mar 2009
Posts: 386
Thanks: 12
Thanked 54 Times in 47 Posts
Rep Power: 67
warj1990 is a name known to allwarj1990 is a name known to allwarj1990 is a name known to allwarj1990 is a name known to allwarj1990 is a name known to allwarj1990 is a name known to all
Quote
#4
06-13-2009, 11:38 AM
Inside that bolt is a long spring. This bike does have auto tension adjustment.

The spring pushes on the chain guide, which has a "click type" tension - to prevent the chain tensioner from loosing. So this bolt and spring can be completely removed and not effect the current tension setting.

You will need to keep looking to figure out the problem. Start with the upper left cover plate with the vent tube. Take that off and look at the chain for timing and tension.

It is difficult to repair and figure out problems via computer.

Best of luck.

Last edited by warj1990; 06-13-2009 at 11:41 AM..
Reply With Quote
warj1990 is offlineReport Post

Join Date: Nov 2008
Age: 27
Posts: 311
Thanks: 2
Thanked 16 Times in 16 Posts
Rep Power: 71
EzekielRoyale has a spectacular aura aboutEzekielRoyale has a spectacular aura about
Location: Pickering, Louisiana

Quote
#5
06-13-2009, 02:04 PM
Well, I didn't start at the top end..I started with the crankcase cover opposite the clutch, I pulled it off to find something that looked like something out of the jetsons or something lol.

The cam chain is tight now, but I believe it needs to be re-timed..any advice on this one???

I thought the hose at the bottom corner was coming off the thermostat, surprise, it was the water pump and it's got an alarming amount of slack in it. It's loose enough that i can, with little effort, remove it from the bottom pulley simply due to the lack of tension.

It's been hitting the side of the case, cutting two grooves (a hair under 1/16th deep) in the crankcase. Also the guide/guard on the right hand side is nearly cut apart from the chain slapping it. Further more behind the main sprocket on the crank is a bolt head that is missing roughtly a 1/4 of the head, from the chain slapping against it. The outside surface of the chain is for the most part smooth, it's missing all the little bumps that a chain typically has. It's a miracle I haven't had it jump off yet!

With the cover off...


Picture of the chain, notice the guide towards the top of the picture as well as the scarring on the case. It doesn't look that bad in the picture, but it's pretty rough in person.
